Web Cam Main Feature |
Video Resolution | 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps | |
Zoom | 15X HD zoom (5X optical and 3X digital) | |
Others | Pan: Motorized ±25°
Tilt: Motorized ±15°
Diagonal Field of View: 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage (field of view + pan and tilt): 132.1° Horizontal x 82.2° Vertical | |
Web Cam Physical Specification |
CAMERA (Dimension) | Height: 164 mm
Width: 910 mm
Depth: 130.5 mm
Lens Depth: 28.8 mm | |
Weight | 7.08 kg | |
Speaker Features |
Input Sensitivity | 92 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter | |
Drivers | 2x 70 mm | |
Others | Rated Power: 8W
THD: 1kHz <2% at 1W
Speaker Sampling Rate: 48 kHz
Impedance: 4 Ohms | |
Microphone Main Features |
Input Sensitivity | >-36dBFS +/-1 dB @ 1Pa | |
Frequency response | 90Hz – 16kHz | |
Pickup Range | Up to 7 m | |
Others | Microphone data rate output: 48KHz
Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
Noise suppression: AI based de-noising algorithm
Add-on Mics: Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms | |
Video controller |
Interface | HDMI Out: 2 (up to 1080p)
HDMI In: 1
USB: 3x Type A, 1x Type C
Network: 10/100/1G Ethernet
WiFi: 802.11a/b/g/n/ac
External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
Remote Control: Bluetooth® Low Energy | |
Others | Security:
Full Disk Encryption: AES-128
Data Encryption: Symmetric Keys, PKI
Device Identity: Protected by device attestation
Device Access: Authenticated using API
Key Protection: Arm TrustZone, RPMP | |
Warranty |
Warranty | 2 years Warranty (Must be Claimed with Full Content & Box) | |
